Sparse Mixture of Experts for Game AI: An Accidental Architecture

I built a sparse MoE to train ML bots for Color Switch before I knew what one was. LSTM networks trained via PPO would overfit to obstacle subsets and fail to generalize. Routing inputs through clustered ensembles fixed it.

The Problem

Color Switch is a mobile game where players navigate obstacles by matching colors. I trained bots in a reinforcement learning setting via PPO.

Individual networks would learn to pass ~30% of obstacles, then fail on the rest. Training new networks learned different subsets. No single network generalized.

The Architecture

1. Cluster obstacles by feature vectors

Each obstacle had metadata: colors, collider counts, rotation speeds, size. Encoded as min-max scaled feature vectors.

K-means clustering grouped visually and mechanically similar obstacles naturally.

1. Train one ensemble per cluster

Separate ensembles (multiple LSTMs each) for each cluster, trained independently.

1. Route inputs to correct ensemble

At inference:

Identify approaching obstacle via spatial hash (O(1) lookup)

Look up obstacle’s cluster ID

Route observations to corresponding ensemble

Weighted average of outputs → action

Router was a cached lookup table. No learned routing, just precomputed K-means assignments.

What Worked

Generalization: Bot trained on Classic mode played 5 different modes without retraining. No previous architecture achieved this.

Modular retraining: New obstacle in a cluster? Retrain one ensemble. Underperforming network? Retrain just that network. Ensembles trained in parallel.

Emergent disentanglement: I now think of this as disentangling the manifold at a coarse level before networks learned finer representations. Obstacles with similar dynamics got processed together. The network didn’t have to learn “this is a circle thing” and “how to pass circle things” simultaneously.

What Didn’t Work

Random speed changes: Obstacles that changed speed mid-interaction broke the bots. Architecture helped but didn’t solve this.

Superhuman performance: Never achieved. Ceiling was “good human player.”

Connection to Transformer MoEs

Didn’t know this was even called a sparse MoE until the GPT-4 leak.

Same pattern: input arrives → router selects expert(s) → outputs combined.

DeepSeek’s MoE paper describes “centroids” as expert identifiers with cosine similarity routing. Mine used Euclidean distance to K-means centroids. Same idea, less sophisticated.

Takeaways

Routing to specialized sub-networks based on input similarity works without transformers

K-means on feature vectors produces surprisingly good routing clusters

Modular architectures enable incremental retraining

Generalization improved when I stopped training one network to handle everything

Happy to answer implementation questions.
